SG3524 Regulating Pulse Width Modulator IC DIP-16 Package

SG3524 Regulating Pulse Width Modulator IC DIP-16 Package

Original price was: ₹89.00.Current price is: ₹59.00.

STOCK: 1 In Stock. (WooHoo!🤗🥰) Order Now!

Same-Day Delivery: Via Porter, within Lucknow City only.

SKU: 33-ERICS010

Quick Review:

  • Package: DIP-16
  • Topology: Push-Pull
  • Adjustable Output: No
  • Input Voltage Range: 8V to 40V.
  • Output Voltage: Configurable depending on application and design.

Shipping: Usually delivered in 3-7 days.

Brand New || Best Quality || Skype and Video Support Available.

Need in Quantity? Let’s Talk!

Availability:

1 in stock

Select Below Products to Add Together:
SG3524 Regulating Pulse Width Modulator IC DIP-16 Package
This item: SG3524 Regulating Pulse Width Modulator IC DIP-16 Package

1 in stock

Original price was: ₹89.00.Current price is: ₹59.00.
Original price was: ₹89.00.Current price is: ₹59.00.
L293D Dual H-Bridge Motor Driver IC DIP-16 Package
L293D Dual H-Bridge Motor Driver IC DIP-16 Package

14 in stock

-
+
Original price was: ₹55.00.Current price is: ₹48.00.

The SG3524 incorporate all the functions required in the construction of a regulating power supply, inverter, or switching regulator on a single chip. They also can be used as the control element for high-power-output applications. The SG3524 was designed for switching regulators of either polarity, transformer-coupled dc-to-dc converters, transformer-less voltage doublers, and polarity-converter applications employing fixed-frequency, pulse-width modulation (PWM) techniques. The complementary output allows either single-ended or push-pull application. Each device includes an on-chip regulator, error amplifier, programmable oscillator, pulse-steering flip-flop, two uncommitted pass transistors, a high-gain comparator, and current-limiting and shutdown circuitry.

The SG3524N by Microchip Technology is a versatile PWM (Pulse Width Modulation) controller IC often used in switch-mode power supply (SMPS) designs, inverters, and DC motor control. Here’s an overview of its key features and specifications:

Pin Configuration:

  1. Inputs: Includes pins for feedback, error amplification, and voltage reference.
  2. Outputs: Two output pins for PWM signal generation.
  3. Control Pins: Oscillator timing and shutdown pins.

Key Features:

  1. Integrated PWM Controller: Designed for switch-mode power supplies.
  2. Adjustable Frequency: Supports oscillation frequencies up to 300 kHz.
  3. Push-Pull or Single-Ended Output: Configurable for different applications.
  4. Built-in Oscillator: Simplifies external circuitry.
  5. Error Amplifier: Onboard amplifier for voltage feedback.
  6. Shutdown and Current Limiting: Ensures protection and control.
  7. Low Standby Current: Optimized for energy-efficient designs.

Applications:

  • Switch-mode power supplies (SMPS).
  • DC-DC converters.
  • Inverters for solar power systems.
  • Battery chargers.
  • Motor speed control.

Technical Specifications:

  • Package: DIP-16
  • Topology: Push-Pull
  • Adjustable Output: No
  • Input Voltage Range: 8V to 40V.
  • Output Voltage: Configurable depending on application and design.
  • Max Output Current: Depends on external components and design configuration.
  • Temperature Range: Standard industrial range for reliable operation.
  • Complete Pulse-Width Modulation (PWM) Power-Control Circuitry
  • Uncommitted Outputs for Single-Ended or Push-Pull Applications
  • Low Standby Current, 8 mA typical

Package Includes:

  • 1 Piece- SG3524 Regulating Pulse Width Modulator IC DIP-16 Package
Weight 2 g
