74LS01 Quad 2-Input NAND Gate IC
Original price was: ₹49.00.₹18.00Current price is: ₹18.00.
Quick Review:
- Logic Family: TTL (Transistor-Transistor Logic)
- Number of Gates: 4
- Number of Inputs per Gate: 2
- Supply Voltage (Vcc): 4.75V to 5.25V
- Input Voltage (Vin): 0V to Vcc
- Output Voltage (Vout): 0V to Vcc
Shipping: Usually delivered in 3-7 days.
Brand New || Best Quality || Skype and Video Support Available.
Need in Quantity? Let’s Talk!
Availability:
Out of stock
The 74LS01 is a high-speed, low-power quad 2-input NAND gate IC designed for use in digital logic applications. This integrated circuit contains four independent NAND gates with two inputs each, providing versatility for various digital logic functions. It operates with TTL logic levels and is suitable for use in a wide range of electronic circuits.
Features:
- High-Speed Operation: Typical propagation delay of 10 ns.
- Low Power Consumption: Efficient power usage for minimal heat generation.
- TTL Compatible: Interoperates with other TTL logic devices.
- Standard Pinout: Compatible with industry-standard pin configuration for easy integration.
- Noise Immunity: High noise margin for reliable operation.
Pin Details
- Pin 1: Input A of Gate 1
- Pin 2: Input B of Gate 1
- Pin 3: Output of Gate 1
- Pin 4: Input A of Gate 2
- Pin 5: Input B of Gate 2
- Pin 6: Output of Gate 2
- Pin 7: Ground (GND)
- Pin 8: Input A of Gate 3
- Pin 9: Input B of Gate 3
- Pin 10: Output of Gate 3
- Pin 11: Input A of Gate 4
- Pin 12: Input B of Gate 4
- Pin 13: Output of Gate 4
- Pin 14: Supply Voltage (Vcc)
Technical Specifications:
- Logic Family: TTL (Transistor-Transistor Logic)
- Number of Gates: 4
- Number of Inputs per Gate: 2
- Supply Voltage (Vcc): 4.75V to 5.25V
- Input Voltage (Vin): 0V to Vcc
- Output Voltage (Vout): 0V to Vcc
- Operating Temperature Range: 0°C to 70°C
- Propagation Delay: 10 ns (typical)
- Power Dissipation: 1.2W (max)
- Output Drive: 10 mA (min) / 15 mA (max)
Applications:
- Digital Logic Circuits: Suitable for creating complex logic functions by combining them with other logic gates
- Data Processing: Used in digital systems for data manipulation and control functions.
- Signal Conditioning: Useful in signal conditioning circuits for logical signal inversion and combination
- Embedded Systems: Ideal for use in embedded electronic systems where space and power efficiency are critical.
Package Includes:
- 1 Piece- 74LS01 Quad 2-Input NAND Gate IC
