74HC86 IC (SMD Package) Quad 2-Input EXOR Gate IC (7486 IC)

Name: 74HC86 IC (SMD Package) Quad 2-Input EXOR Gate IC (7486 IC)
SKU: 33-ERICS024
Availability: InStock

Original price was: ₹49.00.Current price is: ₹28.00.

SKU : 33-ERICS024

STOCK: 1 (WooHoo!) Available

Quick Review:

Operating Voltage: 2V to 6V (Typically 5V)
Input Voltage (VI): 0V to Vcc
High-Level Output Current (IOH): -5.2 mA (typical at 5V)
Low-Level Output Current (IOL): 5.2 mA (typical at 5V)

Shipping: Usually delivered in 3-7 days.

Brand New || Best Quality || Skype and Video Support Available.

Need in Quantity? Let’s Talk!

Availability:

1 in stock

Select Below Products to Add Together:

74HC86 IC (SMD Package) Quad 2-Input EXOR Gate IC (7486 IC)

This item: 74HC86 IC (SMD Package) Quad 2-Input EXOR Gate IC (7486 IC)

1 in stock

HT12D RF Encoder IC

4 in stock

ATmega328P Microcontroller

~~ATmega328P Microcontroller~~

Out of stock

74HC02 Quad 2-Input NOR Gate IC (7402 IC) DIP-14 Package

2 in stock

74HC86 is Quad 2-Input EXOR Gate 14 Pin SMD IC. It is an advanced high speed CMOS 2−input Exclusive−OR gate fabricated with silicon gate CMOS technology. It achieves high speed operation similar to equivalent Bipolar Schottky TTL while maintaining CMOS low power dissipation. Internal circuit is composed of three stages, including a buffer output which provides high noise immunity and stable output. Inputs tolerate voltages up to 7V, allowing interface of 5V systems to 3V systems. Used for Building Arithmetic Logic Circuits, Computational Logic Comparators and Error Detection Circuits and True/Complement Element.

Key Features:

Logic Family: HC (High-Speed CMOS)
Function: Quadruple 2-input XOR gates
Package Type: SMD (Surface Mount Device)
Pin Count: Typically 14 pins (e.g., SOIC-14, TSSOP-14)

Pin Configuration

For a 14-pin package, the typical pinout is:

Pin No.	Function
1	Input A1 (Gate 1)
2	Input B1 (Gate 1)
3	Output Y1 (Gate 1)
4	Input A2 (Gate 2)
5	Input B2 (Gate 2)
6	Output Y2 (Gate 2)
7	Ground (GND)
8	Output Y3 (Gate 3)
9	Input B3 (Gate 3)
10	Input A3 (Gate 3)
11	Output Y4 (Gate 4)
12	Input B4 (Gate 4)
13	Input A4 (Gate 4)
14	Supply Voltage (Vcc)

Technical Specifications:

Operating Voltage: 2V to 6V (Typically 5V)
Input Voltage (VI): 0V to Vcc
High-Level Output Current (IOH): -5.2 mA (typical at 5V)
Low-Level Output Current (IOL): 5.2 mA (typical at 5V)
Propagation Delay: ~6 ns at 5V (typical)
Power Dissipation: Low power CMOS design

Package Includes:

1 Piece- 74HC86 IC (SMD Package) Quad 2-Input EXOR Gate IC (7486 IC)

Weight	2 g
