74LS47 BCD to 7-Segment Decoder/Driver IC (7447 IC) DIP-16 Package

74LS47 BCD to 7-Segment Decoder/Driver IC (7447 IC) DIP-16 Package

Original price was: ₹99.00.Current price is: ₹69.00.

SKU : 33-ERICS021

STOCK: 30 (WooHoo!) Available

Quick Review:

  • Supply Voltage (VCC): 7V
  • Input Voltage (VI): 7 V
  • Operating free-air temperature range: 0°C to +70°C
  • Storage temperature range: –65°C to +150°C

Shipping: Usually delivered in 3-7 days.

Brand New || Best Quality || Skype and Video Support Available.

Need in Quantity? Let’s Talk!

Availability:

30 in stock

The 74LS47 is a BCD (Binary Coded Decimal) to 7-segment display driver that accepts four lines of BCD input data (8421 code). It internally generates the complementary values and decodes the data using seven AND/OR gates with open-collector outputs, which directly drive the segments of a 7-segment display.

Each segment output is capable of sinking up to 24 mA when in the ON (LOW) state and can withstand up to 15V in the OFF (HIGH) state, with a maximum leakage current of  250 µA. The IC also includes auxiliary inputs for functions such as blanking lamp test, and cascadable zero-suppression, making it versatile for a wide range of display applications.

Technical Specifications:

  • Supply Voltage (VCC): 7V
  • Input Voltage (VI): 7 V
  • Operating free-air temperature range: 0°C to +70°C
  • Storage temperature range: –65°C to +150°C

Package Includes:

  • 1 Piece- 74LS47 BCD to 7-Segment Decoder/Driver IC (7447 IC)
Weight 2 g

Shipping

We strive to ensure that your orders reach every corner of India efficiently and reliably. To achieve this, we partner with some of the most trusted courier services in the country, including E-Kart, Amazon Surface, Delhivery, DTDC, Blue Dart, XpressBees, Ecom Express, and India Speed Post—especially for rural areas, based on the most suitable courier partner for each customer’s location.

For interior or remote regions not serviced by private couriers, we rely on India Post to ensure complete coverage.

We make every effort to dispatch orders on the same day they are placed or within 24 hours of receiving the order. Orders placed before 1 PM (IST) are typically shipped the same day, while those placed after 1 PM are scheduled for shipment the next working day.

This level of commitment applies throughout the week, including weekdays, and often extends to weekends and public holidays to serve our customers better.

We also offer local self-pickup options for customers in nearby areas—available on weekdays and partially available on weekends.

Warranty

This item is covered by a 7-day limited warranty from the date of delivery, applicable only to manufacturing defects. This warranty is provided solely to protect customers against any such defects. In the unlikely event of an issue, replacement or reimbursement will be offered after a complete inspection and confirmation of the defect.

What voids the warranty?

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

Note: For your peace of mind, all electronic items are imported and, as such, do not come with a manufacturer’s warranty or guarantee. However, we take great care to ensure product quality—each item is thoroughly inspected before dispatch.

Other Info

  • Country of origin: China
